Glass Sliding Doors Need a Flat Floor — Here's Why

Glass sliding doors are one of the most visible parts of a veranda, and one of the least forgiving when something underneath them isn't right. Unlike a roof panel or a cladding detail, a sliding door has moving parts that depend on precise alignment to work at all. Fit one over ground that isn't flat and the problem doesn't stay hidden for long — panels drag, seals fail, and in time the frame itself can be pulled out of square. Understanding why a flat base matters, what causes the ground not to be flat, and what can be done about it is useful for anyone planning a veranda with glass sliding doors.

Why Sliding Doors Are So Sensitive to a Level Base

A sliding door system works because its track is straight, level, and fixed to a rigid base along its full length. The rollers run along that track under the weight of the glass panel, and any deviation in the track's line — even a few millimetres over the width of the door — changes how the rollers sit and how much resistance they meet as the panel moves. A track fixed to ground that rises, falls, or twists along its length will itself rise, fall, or twist, because the track has no stiffness of its own to resist following the surface beneath it.

The veranda's legs are equally sensitive to the same problem, in a different way. Each leg is designed to sit on a level pad and carry its share of the roof load straight down into the ground. Where the ground varies in height from leg to leg, the legs either have to be shimmed to compensate, or they end up carrying unequal loads — some bearing more than they should, others barely touching down at all. A door frame fixed between legs that aren't level is being asked to hold its shape against a base that is already out of true.

The Most Common Causes of an Uneven Base

Existing patios are the single biggest source of this problem. Many patios were laid for general use rather than for supporting a structure, and a fall of ten to twenty millimetres across a few metres — enough to shed rainwater — is normal and usually invisible to the eye. That same fall is more than enough to throw a sliding door track out of level if the veranda is built directly over it without correction.

Older concrete slabs present a related issue. Concrete poured years ago, particularly without a properly compacted sub-base, can settle unevenly over time. The surface may look flat and solid, but a long level or a laser line across it often reveals a gentle bow or a step that has developed gradually and gone unnoticed because nothing rigid has been built on it before.

Ground that has never been built on at all is its own challenge. Lawn, gravel, or bare earth rarely has any consistent level, and the soil beneath it is often inconsistent in compaction — meaning that even if the visible surface is levelled off, it can settle differently in different spots once weight is applied.

Sloped sites compound all of the above. Where a property sits on a natural slope, the finished floor level needs to be established deliberately rather than assumed, and the further the door run extends across the slope, the more correction is typically required at one end than the other.

Warning Signs of a Base That Wasn't Properly Prepared

The clearest sign is a door that doesn't run smoothly along its full travel — sticking, dragging, or needing extra force at one point but not another. This usually means the track is following a dip or a rise in the base rather than running level.

Gaps that change along the length of the door, or a panel that sits flush at one end but proud at the other, point to the same underlying issue. So does a door that has started to swing open or closed slightly under its own weight when left unlatched, which suggests the frame itself has been pulled very slightly out of square.

Water sitting at the base of the door rather than draining away, particularly after the veranda has been in place for a season or two, can indicate that the ground has settled since installation rather than that it was wrong from the start. Either way, it's worth investigating rather than waiting for it to worsen.

What Proper Installation Does Differently

A correct installation treats the base as something to be established, not assumed. Before any door or leg position is fixed, the existing surface is checked with a level or laser line across the full run, and the actual variation — not the visual impression of flatness — is measured.

Where the variation is small, packers and shims under the legs are usually sufficient, bringing each leg to the correct height without altering the existing surface. Adjustable ground screws or base plates achieve the same result with finer control, and are particularly useful on patios with a deliberate fall for drainage, where the correction needs to vary smoothly along the run rather than being applied as a single fixed amount.

Where the variation is larger, or the existing surface is too soft, cracked, or inconsistent to rely on, a new sub-base or screed is the more reliable option. This is also the default approach where the veranda is being built over bare ground, since there is no existing surface to correct in the first place. Self-levelling compound has a place too, typically on a slab that is structurally sound but has a surface variation too fine to pack out with shims, giving the door a clean, flat reference line to sit on without the cost of a full new base.

The right method depends on the surface in front of the installer, not on a default approach applied regardless of site conditions. This is why a proper site survey, carried out before any door is ordered to size, matters as much for the floor as it does for the structure above it.

What to Do If You Already Have a Problem

If you have glass sliding doors that are sticking, dragging, or showing uneven gaps, the first step is to establish whether the issue is in the track itself or in the base beneath it. A level placed along the track, and another across the leg positions, will usually show which it is fairly quickly.

Where the base has settled since installation, the fix is often less drastic than it sounds — repacking or re-shimming the affected legs can restore the original alignment without touching the door itself. Where the base was never correctly levelled to begin with, the track may need to be lifted, the surface corrected properly, and the door refitted to it. In either case, the longer it's left, the more the frame itself risks being permanently distorted by the uneven load.
